| Model |
SKT30 |
SKT50 |
SKT100 |
SKT200 |
SKT300 |
SKT600 |
SKT1000 |
| Table size (cm) |
40*40 |
50*60 |
70*80 |
100*100 |
120*120 |
150*150 |
200*200 |
| Maximum Specimen Weight(Kg) |
30 |
50 |
100 |
200 |
300 |
600 |
1000 |
| Max acceleration(G) |
half-sine |
600 |
600 |
600 |
500 |
500 |
300 |
300 |
| saw-tooth waveform |
100 |
100 |
100 |
100 |
100 |
100 |
100 |
| square |
150 |
150 |
150 |
150 |
100 |
100 |
100 |
| Pulse Duration (ms) |
half-sine |
40—0.2 |
40~1 |
40~1 |
30~2 |
20~3 |
20~3 |
20~3 |
| saw-tooth waveform |
18~6 |
18~6 |
18~6 |
18~6 |
18~6 |
18~6 |
18~6 |
| square |
|
30~6 |
30~6 |
30~6 |
30~6 |
30~6 |
30~6 |
| Machine Dimension(cm) |
120*110*245 |
130*140*260 |
130*120*260 |
150*130*260 |
200*160*300 |
230*180*310 |
250*220*310 |
| Controller cabinet Dimension(cm) |
W55*D50*H80 |
| Machine Weight(Kg) |
1900 |
2300 |
3200 |
4200 |
8500 |
15500 |
19500 |
| Utility |
3-phase AC380V 50/60Hz 0.5~0.8MPa |
| Requirements |
| Conforming standards |
GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL |
Performance Capability
Shock testing levels vary significantly depending on the product you are evaluating or the conditions you are simulating. The two most important shock performance criteria are velocity change and acceleration level. It is also important to know the shock pulse waveforms—half-sine, sawtooth, or trapezoidal.
Product description
Shock testing systems Design standards: GB/T2423-2008, GJB1217, GJB360.23, GJB150, GJB548, MIL-STD-202F, IEC-68-2-27, MIL-STD-883E, MIL-STD-810F, ISTA, UL
Shock testing systems Applications: aviation, aerospace, vessel, military industry, consumer electronics, automobile, household appliances, display device, etc.
Shock testing System Block Diagram
Company Profile
Labtone Test Equipment Co., Ltd. is a +22 year China manufacture of reliable, cost-effective equipment. Our superior products mainly include Vibration Test Systems, Shock Test Systems, Bump Test Systems, Drop Tester, Packaging Transportation Simulators, and Combined Environmental Test Chambers.
Labtone started business in 2002 in a plant located in Shenzhen and moved to our new, expanded 6,000 square meter facility in Dongguan, Guangdong in 2015. Today, our products are found around the world in electronics, automotive, aerospace, telecommunication, optoelectronics instrument, and industrial machinery applications. Our experience and commitment to new product development have resulted in products that are easy to use, accurate, and designed for decades of service.
Labtone products carry a one-year(12months) warranty. We provide comprehensive factory services and supports, technical literature, manuals and guides as well as having qualified staff and experts to solve your problems.
We sincerely invite you to visit our factory
Customer Services
Presales:
- Technical consultation: test method, laboratory planning, and suggestion.
- Equipment selection: selection scheme, FAQ.
- Product testing scheme.
In-Sales:
- Customer communication and progress report.
- Guidance for pre-installation preparation, equipment commissioning and test run.
- Calibration (when Third Party’s verification is required).
After-Sales:
- Technical training: operation of equipment, daily maintenance, common fault diagnosis, and troubleshooting.
- Scheduled on-site service: Detection of the problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of the latest technical information.
- Technical support: special paid services are provided according to the customer’s needs.
-
